ACE HEAVY MACHINERY

Model	Unit	ACE DC135	ACE DC235	ACE DC345
Suitable excavator	ton	10~22	18~32	24~55
Operating weight	kg	1,030	1,420	1,960
Input power	kW	30	50	80
Max. peak power	kW	40	70	120
Max. operating pressure	bar	350	350	350
Oil flow recommended	L/min	60~150	120~270	180~320
Cutting speed	rpm	90~130	65~113	50~90
Cutting head torque	Nm	5,800	12,500	24,000
Cutter diameter	mm	460	590	620
No. of peak		2 x 24	2 x 25	2 x 30
